Material: Enclosure and parts, door : 1,00 - 1,50 mm mild steel
Mounting plate : 1,50 – 2,00 mm Galvanized steel
Surface Process: Mild Steel Parts: : Iron-phosphate plated, RAL7035 Rough Epoxy, polyester powder-coating
Mounting Plate: Galvanized
IP Rate : IP66, (EN 60 529)
Supply Includes : 1 pcs body,1 set bottom-top lid, 1 pcs front door, 2 pcs support rails, 1 pcs door key, 1 pcs mounting plate
Please see page 268 for technical drawings.
| PDF |
ARES REF. NO |
WIDTH (W) |
HEIGHT(H)
|
DEPTH (D) |
W2 (mm) |
H2 (mm) |
LOCK |
HINGE |
WEIGHT (kg) |
 |
101.250 |
300 |
400 |
150 |
249 |
334 |
1 |
2 |
5,5 |
|
101.251 |
300 |
400 |
200 |
249 |
334 |
1 |
2 |
6,0 |
|
101.252 |
400 |
400 |
200 |
349 |
334 |
1 |
2 |
7,5 |
|
101.253 |
400 |
500 |
200 |
349 |
434 |
1 |
2 |
9,0 |
|
101.254 |
400 |
600 |
200 |
349 |
534 |
2 |
2 |
10,5 |
|
101.255 |
400 |
600 |
280 |
349 |
534 |
2 |
2 |
11,8 |
|
101.265 |
500 |
500 |
200 |
449 |
434 |
2 |
2 |
11.4 |
|
101.266 |
500 |
500 |
280 |
449 |
434 |
2 |
2 |
13.4 |
|
101.256 |
500 |
600 |
200 |
449 |
534 |
2 |
2 |
13,1 |
|
101.257 |
500 |
700 |
200 |
449 |
634 |
2 |
2 |
14,9 |
|
101.258 |
500 |
700 |
280 |
449 |
634 |
2 |
2 |
16,5 |
|
101.259 |
600 |
800 |
200 |
549 |
734 |
2 |
2 |
19,5 |
|
101.260 |
600 |
800 |
280 |
549 |
734 |
2 |
2 |
21,3 |
|
101.261 |
600 |
1000 |
280 |
549 |
934 |
2 |
3 |
34,1 |
|
101.262 |
600 |
1150 |
280 |
549 |
1084 |
3 |
3 |
36,4 |
|
101.267 |
800 |
800 |
200 |
749 |
734 |
2 |
2 |
24.6 |
|
101.268 |
800 |
800 |
280 |
749 |
734 |
2 |
2 |
27.9 |
|
101.263 |
800 |
1000 |
280 |
749 |
934 |
2 |
3 |
40,7 |
|
101.264 |
800 |
1150 |
280 |
749 |
1084 |
3 |
3 |
46,1 |
