Materials : Body, Front Door, Gland Plate Mild Steel Mounting Plate Galvanized Steel
Surface Finishing : Iron-phosphate + electrostatic powder coating RAL 7035
IP Rate : IEC EN 60529 Single Door IP66, Double Door IP54
NEMA Rate : NEMA 4
Standards : IEC 62208 (Enclosure Standards)
Corrosion Rate : C3-M based on TS EN ISO 12944-2
Warranty : KYT-72
Supply Includes : Body, Hinged Door, Gland Plate, Mounting Plate, Assembly Parts
| PDF |
PRODUCT CODE |
W* (mm) |
H* (mm) |
D* (mm) |
WEIGHT (kg) |
M/P W* (mm) |
M/P H* (mm) |
BODY THICKNESSES (mm) |
DOOR THICKNESSES (mm) |
M/P THICKNESSES (mm) |
LOCK (pcs) |
HINGE (pcs) |
VERSION |
 |
DM 286.140 |
600 |
1000 |
400 |
36,73 |
550 |
975 |
1,5 |
2 |
2 |
2 |
3 |
1 |
|
DM 286.124 |
600 |
1200 |
400 |
54,41 |
550 |
1175 |
1,5 |
2 |
2 |
1 |
3 |
2 |
|
DM 288.140 |
800 |
1000 |
400 |
76,45 |
750 |
975 |
1,5 |
2 |
2 |
2 |
3 |
1 |
|
DM 288.124 |
800 |
1200 |
400 |
68,28 |
750 |
1175 |
1,5 |
2 |
2 |
1 |
3 |
2 |
|
DM 281.130 |
1000 |
1000 |
300 |
57,81 |
950 |
975 |
1,5 |
2 |
2 |
4 |
6 |
3 |
|
DM 281.123 |
1000 |
1200 |
300 |
68,07 |
950 |
1175 |
1,5 |
2 |
2 |
2 |
6 |
4 |
|
DM 281.143 |
1000 |
1400 |
300 |
78,33 |
950 |
1375 |
1,5 |
2 |
2 |
2 |
6 |
4 |
|
DM 281.144 |
1000 |
1400 |
400 |
81,80 |
950 |
1375 |
1,5 |
2 |
2 |
2 |
6 |
4 |
|
DM 281.830 |
1200 |
800 |
300 |
54,63 |
1150 |
775 |
1,5 |
2 |
2 |
4 |
4 |
3 |
|
DM 281.840 |
1200 |
800 |
400 |
56,68 |
1150 |
775 |
1,5 |
2 |
2 |
4 |
4 |
3 |
|
DM 281.230 |
1200 |
1200 |
300 |
78,6 |
1150 |
1175 |
1,5 |
2 |
2 |
2 |
6 |
4 |
|
DM 281.140 |
1200 |
1200 |
400 |
81,60 |
1150 |
1175 |
1,5 |
2 |
2 |
2 |
6 |
4 |
