Materials: Body, Front Door, Gland Plate Mild Steel, Mounting Plate Galvanized Steel
Surface Finishing : Iron-phosphate + electrostatic powder coating RAL 7035
IP Rate : IEC EN 60529 Single Door IP66, Double Door IP54
NEMA Rate : NEMA 4
Standards : IEC 62208 (Enclosure Standards)
Corrosion Rate : C3-M based on TS EN ISO 12944-2
Warranty : KYT-72
Supply Includes : Body, Hinged Door, Gland Plate, Mounting Plate, Assembly Parts
ATTENTION: DM 252.321 and all of our products with a depth of 150 mm are without gland plate.
PDF |
PRODUCT CODE |
W* (mm) |
H* (mm) |
D* (mm) |
WEIGHT (kg) |
M/P W* (mm) |
M/P H* (mm) |
BODY THICKNESSES (mm) |
DOOR THICKNESSES (mm) |
M/P THICKNESSES (mm) |
LOCK (pcs) |
HINGE (pcs) |
VERSION |
|
DM 252.315 |
250 |
300 |
150 |
5,09 |
200 |
275 |
1,2 |
1,2 |
2 |
1 |
2 |
1 |
|
DM 252.321 |
250 |
300 |
210 |
6,58 |
200 |
275 |
1,2 |
1,2 |
2 |
1 |
2 |
1 |
|
DM 252.351 |
250 |
350 |
150 |
5,66 |
200 |
325 |
1,2 |
1,2 |
2 |
1 |
2 |
1 |
|
DM 253.315 |
300 |
300 |
150 |
5,75 |
250 |
275 |
1,2 |
1,2 |
2 |
1 |
2 |
1 |
|
DM 253.321 |
300 |
300 |
210 |
7,29 |
250 |
275 |
1,2 |
1,2 |
2 |
1 |
2 |
1 |
|
DM 253.415 |
300 |
400 |
150 |
7,06 |
250 |
375 |
1,2 |
1,2 |
2 |
1 |
2 |
1 |
|
DM 253.421 |
300 |
400 |
210 |
8,71 |
250 |
375 |
1,2 |
1,2 |
2 |
1 |
2 |
1 |
|
DM 253.521 |
300 |
500 |
210 |
10,13 |
250 |
475 |
1,2 |
1,2 |
2 |
2 |
2 |
2 |
|
DM 254.315 |
400 |
300 |
150 |
7,07 |
350 |
275 |
1,2 |
1,2 |
2 |
1 |
2 |
1 |
|
DM 254.421 |
400 |
400 |
210 |
10,49 |
350 |
375 |
1,2 |
1,2 |
2 |
1 |
2 |
1 |
|
DM 254.515 |
400 |
500 |
150 |
10,37 |
350 |
475 |
1,2 |
1,2 |
2 |
2 |
2 |
2 |
|
DM 254.521 |
400 |
500 |
210 |
12,25 |
350 |
475 |
1,2 |
1,2 |
2 |
2 |
2 |
2 |
|
DM 254.526 |
400 |
500 |
260 |
14,02 |
350 |
475 |
1,2 |
1,2 |
2 |
2 |
2 |
2 |
|
DM 254.530 |
400 |
500 |
300 |
15,57 |
350 |
475 |
1,2 |
1,2 |
2 |
2 |
2 |
2 |
|
DM 254.615 |
400 |
600 |
150 |
12,02 |
350 |
575 |
1,2 |
1,2 |
2 |
2 |
2 |
2 |
|
DM 254.621 |
400 |
600 |
210 |
14,01 |
350 |
575 |
1,2 |
1,2 |
2 |
2 |
2 |
2 |
|
DM 254.626 |
400 |
600 |
260 |
15,88 |
350 |
575 |
1,2 |
1,2 |
2 |
2 |
2 |
2 |
|
DM 254.630 |
400 |
600 |
300 |
17,51 |
350 |
575 |
1,2 |
1,2 |
2 |
2 |
2 |
2 |
|
DM 254.830 |
400 |
800 |
300 |
27,06 |
350 |
775 |
1,2 |
1,5 |
2 |
2 |
2 |
2 |
|
DM 255.421 |
500 |
400 |
210 |
12,26 |
450 |
375 |
1,2 |
1,2 |
2 |
2 |
2 |
1 |
|
DM 255.521 |
500 |
500 |
210 |
14,37 |
450 |
475 |
1,2 |
1,2 |
2 |
2 |
2 |
2 |
|
DM 255.530 |
500 |
500 |
300 |
18,50 |
450 |
475 |
1,2 |
1,2 |
2 |
2 |
2 |
2 |
|
DM 255.615 |
500 |
600 |
150 |
15,12 |
450 |
575 |
1,2 |
1,2 |
2 |
2 |
2 |
2 |
|
DM 255.621 |
500 |
600 |
210 |
17,22 |
450 |
575 |
1,2 |
1,5 |
2 |
2 |
2 |
2 |
|
DM 255.626 |
500 |
600 |
260 |
19,18 |
450 |
575 |
1,2 |
1,5 |
2 |
2 |
2 |
2 |
|
DM 255.630 |
500 |
700 |
300 |
20,89 |
450 |
575 |
1,2 |
1,5 |
2 |
2 |
2 |
2 |
|
DM 255.721 |
500 |
700 |
210 |
19,45 |
450 |
675 |
1,2 |
1,5 |
2 |
2 |
2 |
2 |
|
DM 255.726 |
500 |
700 |
260 |
21,50 |
450 |
675 |
1,2 |
1,5 |
2 |
2 |
2 |
2 |
|
DM 256.421 |
600 |
400 |
210 |
14,84 |
550 |
375 |
1,2 |
1,5 |
2 |
2 |
2 |
1 |
|
DM 256.621 |
600 |
600 |
210 |
20,07 |
550 |
575 |
1,5 |
2 |
2 |
2 |
2 |
2 |
|
DM 256.630 |
600 |
600 |
300 |
23,90 |
550 |
575 |
1,5 |
2 |
2 |
2 |
2 |
2 |
|
DM 256.640 |
600 |
600 |
400 |
28,88 |
550 |
575 |
1,5 |
2 |
2 |
2 |
3 |
2 |
|
DM 256.821 |
600 |
800 |
210 |
30,23 |
550 |
775 |
1,5 |
2 |
2 |
2 |
3 |
2 |
|
DM 256.826 |
600 |
800 |
260 |
33,03 |
550 |
775 |
1,5 |
2 |
2 |
1 |
3 |
2 |
|
DM 256.830 |
600 |
800 |
300 |
35,43 |
550 |
775 |
1,5 |
2 |
2 |
2 |
3 |
2 |
|
DM 256.840 |
600 |
800 |
400 |
42,11 |
550 |
775 |
1,5 |
2 |
2 |
1 |
3 |
2 |
|
DM 256.126 |
600 |
1000 |
260 |
39,47 |
550 |
975 |
1,5 |
2 |
2 |
2 |
3 |
3 |
|
DM 256.130 |
600 |
1000 |
300 |
42,06 |
550 |
975 |
1,5 |
2 |
2 |
1 |
3 |
3 |
|
DM 256.123 |
600 |
1200 |
300 |
48,69 |
550 |
1175 |
1,5 |
2 |
2 |
1 |
3 |
5 |
|
DM 258.630 |
800 |
600 |
300 |
29,50 |
750 |
575 |
1,5 |
2 |
2 |
2 |
2 |
2 |
|
DM 258.632 |
800 |
600 |
300 |
29,50 |
750 |
575 |
1,5 |
2 |
2 |
2 |
4 |
4 |
|
DM 258.821 |
800 |
800 |
210 |
38,18 |
750 |
775 |
1,5 |
2 |
2 |
2 |
2 |
2 |
|
DM 258.830 |
800 |
800 |
300 |
43,80 |
750 |
775 |
1,5 |
2 |
2 |
2 |
2 |
2 |
|
DM 258.126 |
800 |
1000 |
210 |
49,37 |
750 |
975 |
1,5 |
2 |
2 |
2 |
3 |
3 |
|
DM 258.130 |
800 |
1000 |
300 |
53,62 |
750 |
975 |
1,5 |
2 |
2 |
2 |
3 |
3 |
|
DM 258.123 |
800 |
1200 |
300 |
62,30 |
750 |
1175 |
1,5 |
2 |
2 |
1 |
3 |
5 |
